Partitioning Techniques in LTLf Synthesis

Partitioning Techniques in LTLf Synthesis

Lucas Martinelli Tabajara, Moshe Y. Vardi

Proceedings of the Twenty-Eighth International Joint Conference on Artificial Intelligence
Main track. Pages 5599-5606. https://doi.org/10.24963/ijcai.2019/777

Decomposition is a general principle in computational thinking, aiming at decomposing a problem instance into easier subproblems. Indeed, decomposing a transition system into a partitioned transition relation was critical to scaling BDD-based model checking to large state spaces. Since then, it has become a standard technique for dealing with related problems, such as Boolean synthesis. More recently, partitioning has begun to be explored in the synthesis of reactive systems. LTLf synthesis, a finite-horizon version of reactive synthesis with applications in areas such as robotics, seems like a promising candidate for partitioning techniques. After all, the state of the art is based on a BDD-based symbolic algorithm similar to those from model checking, and partitioning could be a potential solution to the current bottleneck of this approach, which is the construction of the state space. In this work, however, we expose fundamental limitations of partitioning that hinder its effective application to symbolic LTLf synthesis. We not only provide evidence for this fact through an extensive experimental evaluation, but also perform an in-depth analysis to identify the reason for these results. We trace the issue to an overall increase in the size of the explored state space, caused by an inability of partitioning to fully exploit state-space minimization, which has a crucial effect on performance. We conclude that more specialized decomposition techniques are needed for LTLf synthesis which take into account the effects of minimization.
Keywords:
Planning and Scheduling: Theoretical Foundations of Planning
Agent-based and Multi-agent Systems: Formal Verification, Validation and Synthesis
